Repair kit (air) 476.V353.000 for air-operated diaphragm pump

SKU: 476.V353.000

Category: Repair Kit Selection Tool

Please note the breakdown of the pump article number so that you order the correct repair kit! You can find more information here.

723,45 €

excl. 19% VAT , plus

Manufacturers recommended retail price: 723,45 €

Procurement time: 2 weeks
Delivery time: 1 - 3 Workdays (Abroad deviating)

pc(s).

Procurement time: 2 weeks
Delivery time: 1 - 3 Workdays (Abroad deviating)

Description Kit-Components Characteristics

Description

We supply all Versa-Matic diaphragm pumps parts with fast shipment.

Versamatic a Brand of Warren Rupp is a leading global manufacturer of air-operated double diaphragm pumps, diaphragms, balls, ball seats, casings, o-rings and gaskets.

Repair kit (air) 476.V353.000 for air-operated diaphragm pump

Kit-Components

Kit Number	Kit Description	Quantity	Components	Component Description
476.V353.000	KIT, AIR END, E2 FLAP	1	031.139.000	SLEEVE & SPOOL SET
		1	095.110.558	ASSEM, PILOT VALVE, COND HDPE
		1	095.095.558	.BODY, PILOT VALVE
		1	675.037.080	.RETAINING RING EXT, .530" CS
		1	755.052.000	.SLEEVE ASSY, ALUM PILOT VALVE
		1	775.055.000	.SPOOL ASSY, PILOT VALVE
		2	132.035.357	BUMPER, URETHANE
		2	135.034.506	BUSHING, PLUNGER
		1	360.093.360	GASKET, AIR VALVE, BUNA
		1	360.103.360	GASKET, PILOT VALVE, BUNA
		1	360.104.360	GASKET, VALVE CAP, BUNA
		2	360.105.360	GASKET, CHAMBER, BUNA
		1	508.002.000	GREASE, MULTI-PURPOSE LITHIUM
		2	560.001.360	O-RING, BUNA
		10	560.020.360	O-RING, BUNA
		2	620.007.114	PLUNGER, ACTUATOR
		2	675.042.115	RING, RETAINER
		2	720.004.360	SEAL, U-CUP, BUNA
