Outer Diaphragm Plate, Pvdf – Versamatic KV226B
Right part? Compare the part number and position with the exploded view of your pump (“Spare parts” tab on the pump page). For servicing we recommend the complete repair kits.
▶ Repair kits▶ All spare parts
Genuine spare part Outer Diaphragm Plate, Pvdf (part no. KV226B) for Versamatic air-operated diaphragm pumps of the E2/U2 series. Genuine parts ensure correct fit, tightness and service life.
Technical data
| Part number |
KV226B |
| Original description |
OUTER DIAPHRAGM PLATE, PVDF |
| Component |
Outer Diaphragm Plate, Pvdf |
| Material |
PVDF |
| Material temperature range |
-18 … 121 °C |
| Series |
E2, U2 |
| Quantity per pump |
2 pcs |
| Manufacturer |
Versamatic (Warren Rupp / IDEX), USA |
Fits the following Versamatic pumps
E2 – 6 pumps
E2KA2D229C · E2KA3D539C · E2KA6D669C · E2KA6D669C-CP · E2KS6D669C · E2KS6D6T9C
U2 – 2 pumps
U2KP3D339 · U2KP6D669
Not sure which part you need? Send us an e-mail enquiry with the pump model and serial number from the nameplate.
