Repair kit (air) 476.V046.000 for air-operated diaphragm pump

SKU: 476.V046.000
Category: Repair Kit Selection Tool

Please note the breakdown of the pump article number so that you order the correct repair kit! You can find more information here.

333,90 €
excl. 19% VAT , plus shipping costs
  • Procurement time: 2 weeks
  • Delivery time: 1 - 3 Workdays (Abroad deviating)
pc(s).
  • Procurement time: 2 weeks
  • Delivery time: 1 - 3 Workdays (Abroad deviating)
Description

We supply all Versa-Matic diaphragm pumps parts with fast shipment.

Versamatic a Brand of Warren Rupp is a leading global manufacturer of air-operated double diaphragm pumps, diaphragms, balls, ball seats, casings, o-rings and gaskets.

Repair kit (air) 476.V046.000 for air-operated diaphragm pump

Kit-Components
Kit Number Kit Description Quantity Components Component Description
476.V046.000 U2 AIR SIDE KIT 1 508.002.000 GREASE, MULTI-PURPOSE LITHIUM
1 E200H VALVE INSERT
1 E200J GASKET, AIR VALVE, BUNA
1 E203A SHAFT, PILOT, U2, SS
2 E500D ASY CAP, END ASSY 1" AIR VALVE
5 P24-106P PLASTIC PILOT SPACER
6 P24-107 O-RING, PILOT VALVE, BUNA
2 P24-108 18.8 JAM NYLON LOCK NUT
2 P98-104A SEAL, U-CUP, BUNA
Characteristics
Item information Value
Model: U
Port size: 2
Wetted housing material: SPK
Non-wetted housing material: P
Housing version: 9
Option: HD

Complementary products

Suitable pump(s), repair kits or spare parts
