Repair kit (air) 476.V015.000 for air-operated diaphragm pump

SKU: 476.V015.000
Category: Repair Kit Selection Tool

Please note the breakdown of the pump article number so that you order the correct repair kit! You can find more information here.

243,60 €
excl. 19% VAT , plus shipping costs
  • Immediately available from stock
  • Delivery time: 1 - 3 Workdays (Abroad deviating)
pc(s).
  • Immediately available from stock
  • Delivery time: 1 - 3 Workdays (Abroad deviating)
Description

We supply all Versa-Matic diaphragm pumps parts with fast shipment.

Versamatic a Brand of Warren Rupp is a leading global manufacturer of air-operated double diaphragm pumps, diaphragms, balls, ball seats, casings, o-rings and gaskets.

Repair kit (air) 476.V015.000 for air-operated diaphragm pump

Kit-Components
Kit Number Kit Description Quantity Components Component Description
476.V015.000 E1XA AIR SIDE REPAIR KIT 1 031.V018.000 SLEEVE & SPOOL SET, E1 M
1 508.002.000 GREASE, MULTI-PURPOSE LITHIUM
2 670.V002.554 RETAINER, E1 MAIN SHAFT
1 755.V004.000 SLEEVE ASSY, 1" PILOT
1 775.V005.000 SPOOL ASSY, 1" PILOT (METAL)
2 P50-403 O-RING, BUSHING, BUNA
1 P98-105A U-CUP SEAL, 5/8 x 7/8 x 1/8
1 P98-105B U-CUP SEAL, 7/8 x 1-1/8 x 1/8
1 P98-105CT AIR DIVERTER,E1, METALLIC
1 612.V003.114 VALVE INSERT
2 P98-110 GASKET, END CAP, BUNA
1 P98-111UB GASKET, AIR VALVE, BUNA
Characteristics
Item information Value
Model: E
Port size: 1
Wetted housing material: AS
Non-wetted housing material: AJ
Housing version: 9
Revision level: C
Option: ATEXFP-ATEX
